Pass & Seymour® CA26BRH

Pass & Seymour® CA26 Decorator Heavy Duty Device Box Cover, 2.8 Inch L x 4.56 Inch W, Die-Cast Zinc, 1-Gang, Bronze. For 1 GFCI

  • Manufacturers: Legrand
  • Brand Name: Pass & Seymour®
  • MPN: CA26BRH
  • UPC: 785007248081
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Check Branch and Showroom availability

Pass & Seymour® CA26 Device Box Cover, Decorator, Heavy Duty, 2.8 Inch Length, 4.56 Inch Width, 1-Gang, Die-Cast Zinc, Bronze, Electrostatically Applied Baked Polyester Powder Painted, Horizontal Mount, Weatherproof, Includes: (1) Self-Closing Lid

Type      :      Decorator, Heavy Duty
Series      :      CA26
Length      :      2.8 Inch
Width      :      4.56 Inch
Number of Gangs      :      1
Material      :      Die-Cast Zinc
Color      :      Bronze
Finish      :      Electrostatically Applied Baked Polyester Powder Painted
Mounting Type      :      Horizontal
Enclosure Type      :      Weatherproof
Includes      :      (1) Self-Closing Lid

Designed with heavy duty, die-cast zinc, P&S universal cast covers shrug off the worst weather, while meeting all New regulatory requirements for receptacles and power outlets in outdoor damp locations. Both the Single-and 2-gang covers can meet six applications in one. The single-gang mounts either vertically or horizontally and comes with toggle, decorator and duplex plate inserts. The 2-gang mounts vertically only, but comes with two of each of the plate openings.

  • Broad line of single-gang covers for switches and GFCIs
  • Baked-on electrostatic, polyester, powder paint for superior scratch and corrosion-resistance
  • These self-closing designs feature corrosion-resistant stainless steel springs for enhanced durability
  • No rough edges
  • Covers comply with 2005 NEC section 406.8(A) and 406.8(B)(2)
  • (1) decorator/GFCI device opening

Standard/Approvals: cULus Listed

Application: Commercial and Residential
