Kohler® K-6482-5UA4-20
Send Print
  1. pin-int

Kohler® K-6482-5UA4-20

Kohler® Bellegrove® Modern K-6482-5UA4 Kitchen Sink, Rectangular, Enameled Cast Iron, Suede, 22 Inch H x 33 Inch W

  • Manufacturers: Kohler
  • Brand Name: Kohler®
  • CPEPN: K6482-5UA4-20
  • MPN: K-6482-5UA4-20
  • UPC: 885612113986
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Total Availability: loading
    • This item does not qualify for free shipping

Kohler® Bellegrove® Modern K-6482-5UA4 Kitchen Sink, Rectangular, 22 Inch Overall Height, 33 Inch Overall Width, 9-5/8 Inch Overall Depth, Enameled Cast Iron, Suede, 2 Basins, 29-3/4 Inch L x 18 Inch W x 9 Inch D Left Basin, 29-3/4 Inch L x 18 Inch W x 9 Inch D Right Basin, 5 Faucet Holes, 2-3/8 Inch Faucet Hole, 4 Inch Faucet Center, Undermount, 3-7/8 Inch Drain, 36 Inch W Cabinet, Includes: (2) Bottom Basin Racks, 1054375 23 Inch Undermount Sink Kit, 1159401-7 Cut-Out Template, Sponge Caddy and Enameled Cast Iron Cleaner

Series      :      Bellegrove®, Modern, K-6482-5UA4
Shape      :      Rectangular
Overall Height      :      22 Inch
Overall Width      :      33 Inch
Overall Depth      :      9-5/8 Inch
Material      :      Enameled Cast Iron
Finish      :      Suede
Number of Basins      :      2
Basin Dimensions (Left)      :      29-3/4 Inch L x 18 Inch W x 9 Inch D
Basin Dimensions (Right)      :      29-3/4 Inch L x 18 Inch W x 9 Inch D
Number of Faucet Holes      :      5
Faucet Hole Size      :      2-3/8 Inch
Faucet Centers      :      4 Inch
Mounting Type      :      Undermount
Drain Connection      :      3-7/8 Inch
Minimum Cabinet Size      :      36 Inch W
Includes      :      (2) Bottom Basin Racks, 1054375 23 Inch Undermount Sink Kit, 1159401-7 Cut-Out Template, Sponge Caddy and Enameled Cast Iron Cleaner
Warranty      :      Lifetime Limited

The fresh, versatile design of Bellegrove features two generously sized basins that easily accommodate large pots and pans. This sink includes two reversible racks with innovative wheels on the sides, which allow the racks to be set firmly within either basin to protect the surface from scratches. Bellegrove also comes with a sponge caddy, designed to fit over the sink saddle, and a bottle of cast iron cleaner, which helps the sink stay newer, longer. Crafted from enameled cast iron, this sink resists chipping, cracking, or burning for years of beauty and reliable performance.

  • Double basin sink with a 50/50 split provides increased versatility for any task
  • Oversized holes allow for easy installation of faucets and accessories
  • The fresh, versatile design of Bellegrove features two generously sized basins that can easily accommodate bulky pots and pans
  • This sink includes two reversible racks with innovative wheels on the sides, allowing the racks to be set firmly within either basin
  • Constructed of enameled cast iron which combines strength, durability and insulation benefits
  • Undermount installation gives an integrated graceful look to the sink
  • Rear drain location increases workspace area in the sink as well as storage area underneath
  • All hardware needed for installation included
  • Acid resistant enamel finish

Standard/Approvals: ASME A112.18.2/CSA B125.2 Certified

  • pdfInstallation Sheet https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Kohler_K-5814-4U-7_Installation_Sheet.pdf
  • pdfSpecification Sheet https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Kohler_K-6482-5UA4-20_Specification_Sheet.pdf
  • pdfWarranty Sheet https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Kohler_K-6482-5UA4-20_Warranty_Sheet.pdf
