Cutler-Hammer BR22020

Cutler Hammer Series BR Circuit Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 2 Poles, Light Commercial/Residential

Cutler Hammer Series BR Circuit Breaker, Light Commercial/Residential Commercial/Residential, 120/240 VAC, 20 A, 10 kA Interrupt, Thermal Magnetic, Instantaneous Trip, 2 Poles, Toggle Handle Actuator, Plug-In, 14 - 4 AWG Aluminum/Copper Wire, Plug-On Mount, 60 to 75 deg C

Series      :      Series BR
Commercial/Residential      :      Light Commercial/Residential
Voltage Rating      :      120/240 VAC
Amperage Rating      :      20 A
Interrupt Rating      :      10 kA
Trip Type      :      Thermal Magnetic, Instantaneous
Number of Poles      :      2
Actuator Type      :      Toggle Handle
Connection Type      :      Plug-In
Wire Size      :      14 - 4 AWG Aluminum/Copper
Mounting Type      :      Plug-On
Temperature Rating      :      60 to 75 deg C
  • The circuit breakers shall incorporate trip mechanisms that are mechanically trip-free from the handle
  • Handle position provides visual trip position
  • 1 phase
  • Requires (1) 1 Inch (25.4 mm) spaces
