Cummins® RS13A
Send Print
  1. pin-int

Cummins® RS13A

Cummins® RS13A RS Air-Cooled Residential Generator, 13 kW, 120/240 V, 46/92 A, Air-Cooled V-Twin OHV Engine, 3600 rpm, 60 Hz, Highly Reliable Solenoid Shift Engine Starter, Natural Gas, 1.8 qt Fuel Tank, Automatically, Alternator, Electronic Control

  • Manufacturers: Cummins Filtration
  • Brand Name: Cummins®
  • CPEPN: RS13A
  • MPN: RS13A
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Check Branch and Showroom availability
    • This item does not qualify for free shipping

Cummins® Generator, Residential, Series: RS Air-Cooled, 13 kW, 120/240 V, 46/92 A, 60 Hz, Air-Cooled V-Twin OHV Engine, Engine Specifications: 720 cc Displacement, 8.3:1 Compression Ratio, 759 cfm Cooling Air Volume, Highly Reliable Solenoid Shift Engine Starter, 3600 rpm, Natural Gas, 103000 Btu/hr at 1/4 Inch, 122000 Btu/hr at 1/2 Inch, 172000 Btu/hr at 3/4 Inch, 191000 Btu/hr Full Fuel, 1.8 qt Fuel Tank, Automatically, Alternator, Electronic Control, 61 dBA at 23 ft, Aluminum Housing, Includes: Integrated Oil Drain Valve and Extension Tube

Type      :      Residential
Series      :      RS Air-Cooled
Power Rating      :      13 kW
Voltage Rating      :      120/240 V
Amperage Rating      :      46/92 A
Frequency Rating      :      60 Hz
Engine Type      :      Air-Cooled V-Twin OHV
Engine Specifications      :      720 cc Displacement, 8.3:1 Compression Ratio, 759 cfm Cooling Air Volume
Engine Starter Type      :      Highly Reliable Solenoid Shift
Speed      :      3600 rpm
Fuel Type      :      Natural Gas
Fuel Consumption      :      103000 Btu/hr at 1/4 Inch, 122000 Btu/hr at 1/2 Inch, 172000 Btu/hr at 3/4 Inch, 191000 Btu/hr Full
Fuel Tank Capacity      :      1.8 qt
Control Type      :      Automatically, Alternator, Electronic
Sound Level      :      61 dBA at 23 ft
Housing Material      :      Aluminum
Includes      :      Integrated Oil Drain Valve and Extension Tube
  • Very quiet operation
  • Internet remote monitoring and email notification
  • Automatic load management - the intelligent generator control automatically manages non-essential household loads for maximum utilization of generator power
  • Cummins designed alternator and electronic control
  • Powerful motor starting - starts and runs a 4 ton A/C under full pre-load
  • GFCI "ready"
  • Self-diagnostic capability
  • Service and maintenance information displayed on in home display
  • Easy installation with innovative molded polymer installation base - no need for a concrete pad
  • Electronic governor for precise frequency control
  • Flexible 12 Inch fuel line provided with genset
  • Generator designed and manufactured in the USA
  • Quality power output, less than 5% THD
  • 52.7 Inch L x 40.8 Inch W x 35 Inch H dimension
  • pdfSpecification Sheet https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Cummins_RS13A_Specification_Sheet.pdf
