Pass & Seymour® Single Receptacle, Spec Grade, Commercial Commercial/Residential, 2 Pole, 3 Wires, 14 - 10 AWG Wire, 15 A, 125 VAC, NEMA 5-15R Enclosure, Back/Side Wire Terminal, 1.296 Inch L x 1.19 Inch W x 3.28 Inch H, Nylon, Black, Warranty: 1 Year
| Type | : | Spec Grade |
| Commercial/Residential | : | Commercial |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Wire Size | : | 14 - 10 AWG |
| Amperage Rating | : | 15 A |
| Voltage Rating | : | 125 VAC |
| Enclosure Type | : | NEMA 5-15R |
| Terminal Type | : | Back/Side Wire |
| Dimensions | : | 1.296 Inch L x 1.19 Inch W x 3.28 Inch H |
| Material | : | Nylon |
| Color | : | Black |
| Warranty | : | 1 Year |
- Dual mechanical shutter system to help prevent insertions of foreign objects
- Corrosion-resistant, plated and tabbed steel strap locked in to face and back body to resist pulling away from face/body assembly
- 0.032 Inch thick brass triple-wipe power contacts for lasting retention
- Corrosion-resistant plated steel strap is locked in to the face and back body to resist pulling away from the face/body assembly
- Auto-ground clip assures positive ground
- Easily accessed break-off line-contact connecting tab for fast and easy split-circuitwiring
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates
- Temperature rise maximum 30 deg C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current
- Operating temperature maximum continuous 60 deg C, minimum -40 deg C without impact
Specification Sheet
