Cutler-Hammer MBRLC08B400
Cutler-Hammer MBRLC08B400 House Panel, Compact, Ringless, Type BR, 120/240 V, 400 A, 1 ph, 25 kA, 16-Circuit, 8-Space
- Manufacturers: Eaton
- Brand Name: Cutler-Hammer
- CPEPN: MBRLC08B400
- MPN: MBRLC08B400
- UPC: 786687099284
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Total Availability:
-
Price:
Cutler-Hammer House Panel, Compact, Ringless, Type BR, 120/240 V, 400 A, 1 ph, 25 kA Interrupt, 16 Circuits, CSR2200 Breaker, Copper Bus, 8 Spaces, Bottom Feed, Surface Mounting, NEMA 3R Enclosure, Dimensions: 30.1 Inch L x 36.1 Inch W x 7 Inch H
CSR2200 Breakers included )2)
| Type | : | Compact, Ringless, Type BR |
| Voltage Rating | : | 120/240 V |
| Amperage Rating | : | 400 A |
| Number of Phases | : | 1 ph |
| Interrupt Rating | : | 25 kA |
| Number of Circuits | : | 16 |
| Breaker Type | : | CSR2200 |
| Bus Material | : | Copper |
| Number of Spaces | : | 8 |
| Feed Type | : | Bottom |
| Mounting Type | : | Surface |
| Enclosure Type | : | NEMA 3R |
| Dimensions | : | 30.1 Inch L x 36.1 Inch W x 7 Inch H |
