Zurn® 12-600XL
Send Print
  1. pin-int

Zurn® 12-600XL

Zurn® Wilkins® 12-600XL Pressure Reducing Valve, 1/2 Inch, FNPT x FNPT End, 300 psi, Bronze Body Contact us for better pricing than what is shown

  • Manufacturers: Zurn Elkay Water Solutions
  • Brand Name: Zurn®
  • CPEPN: 12-600XL
  • MPN: 12-600XL
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Total Availability: loading

    • This product ships for free standard ground only.
    Other options will be charged.

The 600XL pressure reducing valve handles sandy, debris-laden water systems for high-flow capacity in residential, commercial and new construction applications. It meets compliance with universal plumbing code. The stainless steel strainer includes a standard 20-mesh configuration and separate-access cover for simplified cleaning, while the bronze threaded bell provides superior corrosion-resistance and speeds access to the internals - together, cutting labor time up to 50%. Internal components of the 600XL utilize a balanced design, providing accurate downstream pressure without consideration of the incoming pressure.

Zurn® Pressure Reducing Valve, 1/2 Inch Nominal, FNPT x FNPT End Style, 300 psi Pressure, 140 deg F, Media: Water, 5-1/2 Inch Inlet to Outlet Length, Bronze Body, Buna N/EPDM Softgoods, Dimensions: 6-1/4 Inch H

California residents see Prop 65 WARNINGS

Nominal Size      :      1/2 Inch
End Style      :      FNPT x FNPT
Pressure Range      :      300 psi
Temperature Rating      :      140 deg F
Media      :      Water
Inlet to Outlet Length      :      5-1/2 Inch
Body Material      :      Bronze
Softgoods Material      :      Buna N/EPDM
Dimensions      :      6-1/4 Inch H
  • Fiber union gasket ensures fast installation
  • Durable construction ensures low maintenance and lifecycle costs
  • Inlet pressure changes with balanced design features to protect the system
  • Stainless steel strainer screen features single-cap removal
  • Threaded bell provides easier access than bolted on bells
  • Low-lead law compliant
  • pdfInstallation Instruction https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Zurn_12_600XL_Installation_Instruction.pdf
  • pdfSpecification Sheet https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Zurn_12_600XL_Specification_Sheet.pdf
