Siemens Contactor, 110 - 120 VAC Coil, 60 A Full Load, 25 hp at 460/480 V, 30 hp at 575/600 V, 3 Poles, 50/60 Hz, Snap Action, 4NO-4NC Contact Form, 4 Auxiliary Contacts, 10 A at 600 VAC (A600), 11 A 1/2 hp at 125 - 250 VAC, 0.6 A at 125 VDC, 0.3 A at 250 VDC Contact Rating, Screw Terminal, Open Enclosure, 158 deg F, Surface Mounting, 4.04 Inch H x 2.87 Inch W x 3.11 Inch D
| Coil Voltage | : | 110 - 120 VAC |
| Full Load Current | : | 60 A |
| Power Rating | : | 25 hp at 460/480 V, 30 hp at 575/600 V |
| Number of Poles | : | 3 |
| Frequency Rating | : | 50/60 Hz |
| Action | : | Snap |
| Contact Form | : | 4NO-4NC |
| Number of Auxiliary Contacts | : | 4 |
| Contact Rating | : | 10 A at 600 VAC (A600), 11 A 1/2 hp at 125 - 250 VAC, 0.6 A at 125 VDC, 0.3 A at 250 VDC |
| Terminal Type | : | Screw |
| Enclosure Type | : | Open |
| Temperature Rating | : | 158 deg F |
| Mounting Type | : | Surface |
| Dimensions | : | 4.04 Inch H x 2.87 Inch W x 3.11 Inch D |
Specification Sheet
