Pass & Seymour® TradeMaster® 2087LA

Pass & Seymour® TradeMaster® 2087 Dead Front Self Test Specification Grade GFCI Receptacle, 14 - 10 AWG, Light Almond

  • Manufacturers: Legrand
  • Brand Name: Pass & Seymour® TradeMaster®
  • CPEPN: 2087LA
  • MPN: 2087LA
  • UPC: 785007036381
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Check Branch and Showroom availability

Pass & Seymour® TradeMaster® 2087 GFCI Receptacle, Dead Front Self Test Specification Grade, Residential Commercial/Residential, 14 - 10 AWG Wire, 20 A, 125 VAC, 1-1/2 hp, 60 Hz, NEMA 5-20R, Screw, Back Wired Terminal, Wallplate Mount, Auto Grounding, 1.72 Inch W x 4.2 Inch H x 0.98 Inch D, Thermoplastic, Light Almond

Type      :      Dead Front, Self Test, Specification Grade
Series      :      TradeMaster®, 2087
Commercial/Residential      :      Residential
Wire Size      :      14 - 10 AWG
Amperage Rating      :      20 A
Voltage Rating      :      125 VAC
Power Rating      :      1-1/2 hp
Frequency Rating      :      60 Hz
Enclosure Type      :      NEMA 5-20R
Terminal Type      :      Screw, Back Wired
Mounting Type      :      Wallplate
Grounding Style      :      Auto
Dimensions      :      1.72 Inch W x 4.2 Inch H x 0.98 Inch D
Material      :      Thermoplastic
Color      :      Light Almond
Warranty      :      1 Year

Conducts an automatic test every three seconds, ensuring it's always ready to protect. If the device fails the test, the indicator light flashes to signal that the GFCI should be replaced. It also has our proven SafeLock™ Protection feature: if critical components are damaged and protection is lost, power to the receptacle is disconnected.

  • Rated as a 1-1/2 hp motor control switch
  • Thinner than competitors’ GFCI Receptacles: leaves more room for wires in the box
  • Auto-Ground clip assures a positive ground to metal box
  • Feed-thru wiring configuration allows GFCI to protect downstream receptacles
  • Prevents line-load reversal miswire: no power to the face or downstream receptacles if wired incorrectly
  • Two back-wire holes per terminal
  • Ground screw has back-wire clamp for easy installation
  • 10kA short circuit rating
  • Mounting screws are shipped captive in the device and wall plate for easier installation
  • Extra-long strap
  • Button colors match the device face
  • Dual-direction test and reset buttons
  • Supplied with matching TP wall plate
  • Class A rated GFCI
  • Side or internal screw-pressure-plate back wire with no. 10 - 14 AWG solid or stranded copper wire

Standard/Approvals: Federal Spec WC59, UL 498 Listed, cULus Listed

  • pdfBrochure https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_2087I_Brochure.pdf
  • pdfInstallation Sheet https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_2087I_Installation_Sheet.pdf
  • pdfSpecification Sheet https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_2087I_Specification_Sheet.pdf
