Siemens 42BF15AF

Siemens 42BF15AF Class 42 Non-Reversing Definite Purpose Contactor, Snap, 110 - 120 VAC Coil, 30 A, 4NO-4NC, 2 Pole, 2 hp at 120 V, 5 hp at 240 V, 50 - 60 Hz, 4 Auxiliary Contacts, Screw Terminal, Open, 158 deg F, Surface Mount

Siemens Definite Purpose Contactor, Class 42 Non-Reversing, 110 - 120 VAC Coil, 30 A Full Load, 2 hp at 120 V, 5 hp at 240 V, 2 Pole, 50 - 60 Hz, Snap, 4NO-4NC, 4 Auxiliary Contacts, 10 A at 600 VAC (A600), 11 A 1/2 hp at 125 - 250 VAC, 0.6 A at 125 VDC, 0.3 A at 250 VDC Contact, Screw Terminal, Open, 158 deg F, Surface Mount, 3.69 Inch H x 2.38 Inch W x 2.87 Inch D

Type      :      Class 42 Non-Reversing
Coil Voltage      :      110 - 120 VAC
Full Load Current      :      30 A
Power Rating      :      2 hp at 120 V, 5 hp at 240 V
Number of Poles      :      2
Frequency Rating      :      50 - 60 Hz
Action      :      Snap
Contact Form      :      4NO-4NC
Number of Auxiliary Contacts      :      4
Contact Rating      :      10 A at 600 VAC (A600), 11 A 1/2 hp at 125 - 250 VAC, 0.6 A at 125 VDC, 0.3 A at 250 VDC
Terminal Type      :      Screw
Enclosure Type      :      Open
Temperature Rating      :      158 deg F
Mounting Type      :      Surface
Dimensions      :      3.69 Inch H x 2.38 Inch W x 2.87 Inch D
  • Snap on auxiliary contacts
  • Enclosed body design
  • 600 VAC operating voltage for main current circuit
  • 120 A operating current
  • 250000 cycles mechanical service life (switching cycles) of the main contacts
  • Box lug electrical connection for supply voltage lineside
  • 25 lbf-in tightening torque for supply
  • pdfSpecification Sheet https://www.cpesupply.com//ASSETS/DOCUMENTS/ITEMS/EN/Siemens_42BF15AF_Specification_Sheet.pdf
